009155005852006 - Kyocera AVX

009155005852006 Details

• Manufacturer Part Number:

  009155005852006

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Kyocera AVX Components

• YTEOL:

  12

• Board Mounting Option:

  COMPLIANT BOARDLOCK

• Body Breadth:

  0.197 inch

• Body Depth:

  0.136 inch

• Body Length:

  0.486 inch

• Connector Type:

  PCB CONNECTOR

• Contact Gender:

  MALE

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  COMPRESSION

• Durability:

  5000 Cycles

• Filter Feature:

  NO

• Insulator Color:

  BLACK

• Insulator Material:

  GLASS FILLED POLYAMIDE46

• Mating Contact Pitch:

  0.079 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• Packing Method:

  TR, 13 INCH

• Plating Thickness:

  16u inch

• Rated Current (Signal):

  1.5 A

• Reference Standard:

  UL

• Terminal Pitch:

  2 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  5

• UL Flammability Code:

  94V-0
