The recommended torque value for the screw terminals is 0.5 Nm to 1.5 Nm, depending on the wire size and type. It's essential to follow the recommended torque value to ensure reliable connections and prevent damage to the connector.
Yes, the 02011608101 connector is designed to withstand high-vibration environments. However, it's crucial to ensure that the connector is properly secured and the screw terminals are tightened to the recommended torque value to prevent loosening or damage.
The 02011608101 connector has a IP67 rating, which means it's protected against dust and water ingress. However, it's essential to ensure that the connector is properly sealed and protected from extreme temperatures, humidity, and chemical exposure to ensure reliable operation.
While the 02011608101 connector is designed for AWG 20-16 wires, it may be possible to use it with other wire sizes. However, it's essential to consult with HARTING's technical support or a qualified engineer to ensure that the connector can accommodate the desired wire size and meet the required electrical and mechanical specifications.
The 02011608101 connector has an operating temperature range of -40°C to 125°C. However, it's essential to consider the temperature rating of the wire and other components in the system to ensure reliable operation.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
02011608101 Overview
Use the download button to access the 02011608101 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 02011,
or try a keyword search, such as Headers and Edge Type Connectors
