031-6293 - Amphenol

031-6293 Details

• Manufacturer Part Number:

  031-6293

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  6.9

• Additional Feature:

  INSERTION LOSS MAX AT: 9GHZ

• Body Breadth:

  0.625 inch

• Body Depth:

  1.5 inch

• Body Diameter:

  0.505 inch

• Body Length:

  0.58 inch

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF TNC CONNECTOR

• Contact Finish Mating:

  GOLD

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  FEMALE

• Contact Resistance:

  1.5 mΩ

• Contact Style:

  COAX

• Coupling Type:

  THREADED

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  1500VAC V

• Durability:

  500 Cycles

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Loss:

  0.18 dB

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  POLYTETRAFLUOROETHYLENE

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number of Ports:

  1

• Operating Frequency-Max:

  11 GHz

• Operating Temperature-Max:

  165 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  YES

• Shell Finish:

  NICKEL

• Shell Material:

  BRASS

• Terminal Length:

  0.131 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.35
