0476591101 - Molex

0476591101 Details

• Manufacturer Part Number:

  0476591101

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Molex

• YTEOL:

  7.75

• Board Mounting Option:

  LOCKPIN

• Body Breadth:

  0.216 inch

• Body Depth:

  0.337 inch

• Body Length:

  0.59 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  HDMI CONNECTOR

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  FEMALE

• Contact Pattern:

  STAGGERED

• Contact Style:

  TELCOM, MODULAR

• Durability:

  10000 Cycles

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulator Color:

  BLACK

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e4

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  1

• Number of Ports:

  1

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• Plating Thickness:

  15u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  0.5 A

• Shell Finish:

  NICKEL

• Shell Material:

  BRASS

• Terminal Pitch:

  0.02 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  19
