0483950003 - Molex

0483950003 Details

• Manufacturer Part Number:

  0483950003

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Molex

• YTEOL:

  0

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  USB CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Style:

  USB, SER A FLAT

• Dielectric Withstanding Voltage:

  140VAC V

• Durability:

  5000 Cycles

• Insertion Force-Max:

  35.00576 N

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYETHYLENE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.4986 mm

• Rated Current (Signal):

  1.8 A

• Terminal Length:

  0.059 inch

• Terminal Pitch:

  2.0066 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  9

• Withdrawl Force-Min:

  .4726 N
