09032246804 - HARTING

09032246804 Details

• Manufacturer Part Number:

  09032246804

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Germany

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  HARTING Technology Group

• YTEOL:

  8

• Additional Feature:

  STANDARD: DIN 41612, TERMINAL PITCH FOR POWER CONTACTS: 7.62 MM

• Body Breadth:

  0.413 inch

• Body Depth:

  0.496 inch

• Body Length:

  3.736 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD EURO CONNECTOR

• Contact Arrangement:

  S24C8

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  GOLD OVER NICKEL

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Style:

  HYBRID

• DIN Conformance:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mixed Contacts:

  YES

• Mounting Option 1:

  HOLE .099-.111

• Mounting Option 2:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Rows Loaded:

  3

• Option:

  GENERAL PURPOSE

• Reference Standard:

  UL

• Terminal Length:

  0.114 inch

• Terminal Pitch:

  2.54 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  32

• UL Flammability Code:

  94V-0
