09P30-03-1-04N - Grayhill

09P30-03-1-04N Details

• Manufacturer Part Number:

  09P30-03-1-04N

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.20

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Grayhill Inc

• YTEOL:

  6

• Actuator Type:

  STANDARD TYPE

• Contact (AC) Max Rating R Load:

  .25A@115VAC

• Contact Current(AC)-Max:

  0.25 A

• Contact Current(DC)-Max:

  0.25 A

• Contact (DC) Max Rating R Load:

  .25A@28VDC

• Contact Voltage(AC)-Max:

  115 V

• Contact Voltage(DC)-Max:

  28 V

• Indexing Angle:

  30 deg

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  4

• Number of Switch Sections:

  3

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP4T

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  GOLD

• Termination Type:

  SOLDER
