1-1376387-2 - TE Connectivity

1-1376387-2 Details

• Manufacturer Part Number:

  1-1376387-2

• Brand Name:

  AMP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.27

• Board Mounting Option:

  SOLDERABLE RETENTION CLIPS

• Body Breadth:

  0.555 inch

• Body Depth:

  0.55 inch

• Body Length:

  0.653 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  RECTANGULAR POWER CONNECTOR

• Contact Arrangement:

  S0P6

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Pattern:

  RECTANGULAR

• DIN Conformance:

  NO

• Durability:

  25 Cycles

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  9.7856 N

• Insulation Resistance:

  500000000 Ω

• Insulator Color:

  RED

• Insulator Material:

  GLASS FILLED POLYAMIDE66

• MIL Conformance:

  NO

• Mains Connector Rating:

  10A

• Mating Contact Row Spacing:

  0.244 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  FRICTION RAMP

• Mounting Option 2:

  LATCHING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -30 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Plating Thickness:

  39.37u inch

• Rated Current (Signal):

  10 A

• Reference Standard:

  CSA, UL

• Terminal Length:

  0.138 inch

• Terminal Pitch:

  5 mm

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  6

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  1.4734 N
