1-1462051-1 - TE Connectivity

1-1462051-1 Details

• Manufacturer Part Number:

  1-1462051-1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Factory Lead Time:

  30 Weeks, 6 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.25

• Body Breadth:

  7.2 mm

• Body Height:

  10 mm

• Body Length or Diameter:

  14.6 mm

• Characteristic Impedance:

  50 Ω

• Coil Current(DC)-Max:

  0.047 A

• Coil Operate Voltage(DC):

  2.25 V

• Coil Power:

  140 mW

• Coil Release Voltage(DC):

  2.25 V

• Coil Resistance:

  64 Ω

• Coil Voltage(AC)-Max:

  3 V

• Coil Voltage(DC)-Max:

  3 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  2A@250VAC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Rating R Load:

  2A@220VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  220 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  1000 Vrms

• Dielectric Strength Between Open Contacts:

  600 Vrms

• End Contact Material:

  NICKEL

• Insertion Loss-Max:

  -0.03 dB

• Insulation Resistance:

  1000000000000 Ω

• Isolation-Max:

  -80 dB

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  8 ms

• Operating Frequency-Max:

  3000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Packing Method:

  BOX; TR

• Physical Dimension:

  14.6 X 7.2 X 9.1

• Reference Standard:

  UL

• Relay Action:

  LATCHED

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  RF RELAY

• Release Time:

  8 ms

• Sealing:

  IP67; RT3

• Surface Mount:

  NO

• Switching Time:

  16 ms

• Termination Type:

  SOLDER/QUICK CONNECT

• VSWR:

  1.05
