1-1571983-3 - TE Connectivity

1-1571983-3 Details

• Manufacturer Part Number:

  1-1571983-3

• Brand Name:

  Alcoswitch

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Factory Lead Time:

  32 Weeks, 2 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  8.1

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  ROHS COMPLIANT

• Body Breadth:

  6.2 mm

• Body Height:

  2.31 mm

• Body Length or Diameter:

  13.82 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(AC)-Max:

  0.1 A

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  .025A@24VDC

• Contact Function:

  ON-OFF

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  50 V

• Dielectric Withstand Volts:

  300VAC V

• Electrical Life:

  1000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  POLYPHENYLENE SULPHIDE

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYPHENYLENE SULPHIDE

• JESD-609 Code:

  e4

• Mounting Feature:

  PANEL MOUNT

• Number of Positions:

  10

• Number of Switch Sections:

  10

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Packing Method:

  TUBE

• Sealing:

  TAPE SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
