1-1571986-1 - TE Connectivity

1-1571986-1 Details

• Manufacturer Part Number:

  1-1571986-1

• Brand Name:

  Alcoswitch

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.3

• Actuator Color:

  BLACK

• Actuator Type:

  ROCKER

• Body Breadth:

  6.86 mm

• Body Color:

  BLACK

• Body Height:

  12.7 mm

• Body Length or Diameter:

  12.7 mm

• Center Contact Plating:

  SILVER

• Contact (AC) Max Rating R Load:

  5A@120VAC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Rating R Load:

  5A@28VDC

• Contact Function:

  ON-ON

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  28 V

• Electrical Life:

  40000 Cycle(s)

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPDT

• Switch Type:

  ROCKER SWITCH

• Termination Type:

  SOLDER
