1-1612962-3 - TE Connectivity

1-1612962-3 Details

• Manufacturer Part Number:

  1-1612962-3

• Brand Name:

  AMP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  TE Connectivity

• Board Mounting Option:

  LOCATING POST

• Body Breadth:

  0.189 inch

• Body Depth:

  0.275 inch

• Body Length:

  1.263 inch

• Body/Shell Style:

  PLUG

• Connector Type:

  PCB CONNECTOR

• Contact Arrangement:

  S0P10

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Style:

  BLADE PIN-SKT

• DIN Conformance:

  NO

• Durability:

  6000 Cycles

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYETHYLENE

• MIL Conformance:

  NO

• Mains Connector Rating:

  115/230VAC

• Mixed Contacts:

  NO

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -20 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Rated Current (Signal):

  8 A

• Rated Voltage:

  30 V

• Reference Standard:

  UL

• Terminal Length:

  0.148 inch

• Terminal Pitch:

  2 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  10
