1-2214934-4 - TE Connectivity

1-2214934-4 Details

• Manufacturer Part Number:

  1-2214934-4

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Additional Feature:

  TERMINAL PITCH FOR POWER CONTACTS IS 7.3 MM

• Connector Type:

  BOARD CONNECTOR

• Contact Arrangement:

  S12P4

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Material:

  NOT APPLICABLE

• DIN Conformance:

  NO

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• MIL Conformance:

  NO

• Mains Connector Rating:

  28.5A

• Mixed Contacts:

  YES

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Plating Thickness:

  30u inch

• Rated Current (Signal):

  28.5 A

• Rated Voltage:

  100 V

• Terminal Pitch:

  7.26 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  16
