1-2321775-6 - TE Connectivity

1-2321775-6 Details

• Manufacturer Part Number:

  1-2321775-6

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  TE Connectivity

• YTEOL:

  9

• Body Breadth:

  0.472 inch

• Body Depth:

  0.472 inch

• Body Length:

  0.957 inch

• Characteristic Impedance:

  50 Ω

• Connector Type:

  COMBINATION LINE CONNECTOR

• Contact Gender:

  MALE

• DIN Conformance:

  NO

• EMI Shielded:

  YES

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Color:

  BROWN

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• MIL Conformance:

  NO

• Mains Connector Rating:

  .3A

• Mixed Contacts:

  NO

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Frequency-Max:

  9 GHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  0.3 A

• Rated Voltage:

  60 V

• Shell Material:

  ZINC ALLOY

• Terminal Pitch:

  4 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  4
