1-390261-9 - TE Connectivity

1-390261-9 Details

• Manufacturer Part Number:

  1-390261-9

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Additional Feature:

  STANDARD: UL 94V-0, LOW PROFILE

• Body Breadth:

  0.394 inch

• Body Depth:

  0.201 inch

• Body Length:

  1.3 inch

• Contact Configuration:

  RECTANGLE

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Material:

  NOT SPECIFIED

• Contact Style:

  LEAF

• Current Rating:

  1 A

• Device Socket Type:

  IC SOCKET

• Device Type Used On:

  DIP28

• Dielectric Withstanding Voltage:

  1000VAC V

• Housing Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• Insulation Resistance:

  1000000000 Ω

• Mating Contact Pitch:

  0.1 inch

• Mounting Style:

  STRAIGHT

• Number of Contacts:

  28

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  0.30000000000000004 mm

• Terminal Pitch:

  2.54 mm

• Termination Type:

  SOLDER
