1-5435802-5 - TE Connectivity

1-5435802-5 Details

• Manufacturer Part Number:

  1-5435802-5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Actuator Type:

  PIANO TYPE

• Additional Feature:

  LOW PROFIE

• Body Breadth:

  7.366 mm

• Body Color:

  BLACK

• Body Height:

  7.36 mm

• Body Length or Diameter:

  12.19 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(AC)-Max:

  1.5 A

• Contact Current(DC)-Max:

  1.5 A

• Contact (DC) Max Rating R Load:

  0.025A@24VDC

• Contact Resistance:

  0.1 mΩ

• Contact Timing:

  BREAK-BEFORE-MAKE

• Contact Voltage(DC)-Max:

  50 V

• Dielectric Withstand Volts:

  500VDC V

• Electrical Life:

  7000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  TIN

• Housing Material:

  GLASS FILLED POLYESTER

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  GLASS FILLED POLYESTER

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  4

• Number of Switch Sections:

  4

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• PCB Hole Count:

  8

• Packing Method:

  BOX; TUBE

• Solderability:

  WAVE

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  PIANO DIP SWITCH

• Terminal Length:

  0.14 inch

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  WIRE
