1-776163-2 - TE Connectivity

1-776163-2 Details

• Manufacturer Part Number:

  1-776163-2

• Brand Name:

  AMP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  13 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.44

• Additional Feature:

  POLARIZED

• Board Mounting Option:

  BOARD LOCK

• Body Breadth:

  1.498 inch

• Body Depth:

  1.49 inch

• Body Length:

  3.03 inch

• Connector Type:

  COMBINATION LINE CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• DIN Conformance:

  NO

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• MIL Conformance:

  NO

• Mains Connector Rating:

  17A

• Mixed Contacts:

  NO

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Number of Rows Loaded:

  3

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  17 A

• Reference Standard:

  UL

• Terminal Pitch:

  4 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  35

• UL Flammability Code:

  94V-0
