1.5KE15AHE3_A/C - Vishay

1.5KE15AHE3_A/C Details

• Manufacturer Part Number:

  1.5KE15AHE3_A/C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Date Of Intro:

  2016-10-23

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  0

• Additional Feature:

  EXCELLENT CLAMPING CAPABILITY

• Breakdown Voltage-Max:

  15.8 V

• Breakdown Voltage-Min:

  14.3 V

• Breakdown Voltage-Nom:

  15.05 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  21.2 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• Forward Voltage-Max (VF):

  3.5 V

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Non-rep Peak Rev Power Dis-Max:

  1500 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Packing Method:

  TR, 13 INCH

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  6.5 W

• Reference Standard:

  AEC-Q101; UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  12.8 V

• Reverse Current-Max:

  1 µA

• Reverse Test Voltage:

  12.8 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
