1.5KE20A_B0_10001 - PANJIT

1.5KE20A_B0_10001 Details

• Manufacturer Part Number:

  1.5KE20A_B0_10001

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  DO-201AE

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  PanJit Semiconductor

• YTEOL:

  6.33

• Additional Feature:

  EXCELLENT CLAMPING CAPABILITY

• Breakdown Voltage-Max:

  21 V

• Breakdown Voltage-Min:

  19 V

• Breakdown Voltage-Nom:

  20 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  27.7 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-201AE

• JESD-30 Code:

  O-PALF-W2

• Non-rep Peak Rev Power Dis-Max:

  1500 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  17.1 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
