1.5KE24A - STMicroelectronics

1.5KE24A Details

• Manufacturer Part Number:

  1.5KE24A

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DO-201

• Package Description:

  ROHS COMPLIANT, PLASTIC PACKAGE-2

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Additional Feature:

  UL RECOGNIZED

• Breakdown Voltage-Max:

  25.2 V

• Breakdown Voltage-Min:

  22.8 V

• Breakdown Voltage-Nom:

  24 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  42.8 V

• Configuration:

  SINGLE, 1 CHANNEL

• Diode Capacitance-Min:

  3500 pF

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-201

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Non-rep Peak Rev Power Dis-Max:

  1500 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Packing Method:

  AMMO PACK

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  5 W

• Qualification Status:

  Not Qualified

• Reference Standard:

  IEC-61000-4-2, 4-4, 4-5; MIL-STD-750

• Rep Pk Reverse Voltage-Max:

  20.5 V

• Reverse Current-Max:

  5 µA

• Reverse Test Voltage:

  20.5 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
