1.5KE51ARL4G - onsemi

1.5KE51ARL4G Details

• Manufacturer Part Number:

  1.5KE51ARL4G

• Brand Name:

  ON Semiconductor

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  LEAD FREE, PLASTIC, CASE 41A-04, 2 PIN

• Pin Count:

  2

• Manufacturer Package Code:

  41A-04

• Similar Group:

  DI1010061038

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  onsemi

• Additional Feature:

  EXCELLENT CLAMPING CAPABILITY, HIGH RELIABILITY, LOW IMPEDANCE

• Breakdown Voltage-Max:

  53.6 V

• Breakdown Voltage-Min:

  48.5 V

• Breakdown Voltage-Nom:

  51 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  70.1 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Non-rep Peak Rev Power Dis-Max:

  1500 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  5 W

• Qualification Status:

  Not Qualified

• Reference Standard:

  UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  43.6 V

• Surface Mount:

  NO

• Technology:

  ZENER

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
