1.5KE6.8A - LITTELFUSE

1.5KE6.8A Details

• Manufacturer Part Number:

  1.5KE6.8A

• Pbfree Code:

  No

• Part Life Cycle Code:

  Transferred

• Package Description:

  PLASTIC, CASE 8, 2 PIN

• Pin Count:

  2

• Manufacturer Package Code:

  CASE 8

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  6.41

• Additional Feature:

  EXCELLENT CLAMPING CAPABILITY

• Breakdown Voltage-Max:

  7.14 V

• Breakdown Voltage-Min:

  6.45 V

• Breakdown Voltage-Nom:

  6.8 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  10.5 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-201

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  1500 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  265

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  6.5 W

• Qualification Status:

  Not Qualified

• Reference Standard:

  UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  5.8 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Time@Peak Reflow Temperature-Max (s):

  10
