101E10119X - CONEC

101E10119X Details

• Manufacturer Part Number:

  101E10119X

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Conec Corporation

• YTEOL:

  6

• Additional Feature:

  STANDARD: DIN 41617

• Board Mounting Option:

  HOLE .099-.111

• Body Depth:

  0.335 inch

• Body Length:

  3.567 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD EURO CONNECTOR

• Contact Finish Mating:

  SILVER

• Contact Finish Termination:

  Silver (Ag)

• Contact Gender:

  MALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  15 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  YES

• Durability:

  500 Cycles

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  2.224 N

• Insulation Resistance:

  10000000000 Ω

• Insulator Color:

  GRAY

• Insulator Material:

  GLASS FILLED POLYCARBONATE

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mating Contact Pitch:

  0.197 inch

• Mating Contact Row Spacing:

  0.197 inch

• Mixed Contacts:

  NO

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  5.0038 mm

• Rated Current (Signal):

  4 A

• Reference Standard:

  UL

• Terminal Length:

  0.283 inch

• Terminal Pitch:

  5 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  31
