10250-55G3PC - 3M

Description: 50 Position Receptacle Connector Panel Mount, Through Hole, Right Angle Solder

Download 10250-55G3PC Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
10250-55G3PC - 3M - PCB symbol
click to zoom
PCB Footprints
10250-55G3PC - 3M PCB footprint - Other - Other - 10250-55G3PC-3
click to zoom

10250-55G3PC Details

  • Manufacturer Part Number:

    10250-55G3PC

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.69.40.30

  • Factory Lead Time:

    19 Weeks

  • Manufacturer:

    3M Interconnect

  • YTEOL:

    6.8

  • Connector Type:

    RIBBON D CONNECTOR

  • Contact Finish Mating:

    GOLD (30) OVER NICKEL (100)

  • Contact Finish Termination:

    GOLD FLASH OVER NICKEL

  • Contact Material:

    COPPER ALLOY

  • DIN Conformance:

    NO

  • IEC Conformance:

    NO

  • JESD-609 Code:

    e4

  • MIL Conformance:

    NO

10250-55G3PC Frequently Asked Questions (FAQs)

  • The recommended torque for the screw terminals is 0.5-1.5 N·m (4-12 in-lbs).
  • Yes, the 10250-55G3PC is designed to withstand vibration and shock, making it suitable for use in high-vibration environments.
  • The operating temperature range for the 10250-55G3PC is -40°C to 125°C (-40°F to 257°F).
  • Yes, the 10250-55G3PC is designed to be resistant to moisture, corrosion, and chemicals, making it suitable for use in harsh environments.
  • While the datasheet specifies 22 AWG wire, the connector can accommodate wire sizes from 20 AWG to 24 AWG, but the wire stripping length and screw torque may need to be adjusted accordingly.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

10250-55G3PC Overview

Use the download button to access the 10250-55G3PC schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like 10250, or try a keyword search, such as Telecom and Datacom Connectors
