The recommended soldering temperature is 260°C (500°F) with a maximum soldering time of 5 seconds. Exceeding these limits can damage the capacitor.
Yes, the 106MWR250K is designed to withstand high-vibration environments. It meets the vibration test requirements of IEC 60068-2-6, which involves 10-2000 Hz frequency sweeps at 10G acceleration.
The 106MWR250K has a moisture sensitivity level (MSL) of 2, which means it can withstand normal humidity levels. However, it's not designed for immersion in water or exposure to high-pressure water jets. If you need a capacitor for wet environments, consider a different part number with a higher MSL rating.
The ESR of the 106MWR250K is not explicitly stated in the datasheet, but it's typically around 1-2 ohms for this type of capacitor. If you need a specific ESR value, contact Illinois Capacitor Inc or consult their application notes.
Yes, the 106MWR250K is RoHS (Restriction of Hazardous Substances) and REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) compliant, meeting the requirements of EU directives 2011/65/EU and 1907/2006/EC, respectively.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
106MWR250K Overview
Use the download button to access the 106MWR250K schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like 106MW,
or try a keyword search, such as Ceramic Capacitors
