109K - Hammond Manufacturing

109K Details

• Manufacturer Part Number:

  109K

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Country Of Origin:

  Canada

• ECCN Code:

  EAR99

• Manufacturer:

  Hammond Manufacturing

• YTEOL:

  6

• Application:

  AUDIO; ISOLATION; LINE MATCHING

• Height:

  23.368 mm

• Length:

  33.401 mm

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Operating Frequency-Max:

  50 kHz

• Operating Frequency-Min:

  0.3 kHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Primary Impedance:

  1500 OHMS CT

• Secondary Impedance:

  600 OHMS CT

• Surface Mount:

  NO

• Transformer Type:

  GENERAL PURPOSE AUDIO TRANSFORMER

• Width:

  23.622 mm
