1119810 - Phoenix Contact

1119810 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material. It's essential to consult the Phoenix Contact application notes for more detailed guidance.
• Can I use this connector in high-vibration environments?
  Yes, the 1119810 connector is designed to withstand vibrations up to 10 g according to IEC 60068-2-6. However, it's crucial to ensure proper mounting and screwing to prevent damage or disconnection.
• Is the connector suitable for use in humid or wet environments?
  The 1119810 connector has a IP20 rating, which means it's protected against solid objects larger than 12 mm, but not against water or moisture. For humid or wet environments, consider using a connector with a higher IP rating or applying additional sealing measures.
• Can I use this connector with wire sizes other than the recommended AWG 20-24?
  While the datasheet recommends AWG 20-24, the connector can accommodate smaller wire sizes (e.g., AWG 26-28) with reduced current ratings. However, using larger wire sizes may compromise the connector's reliability and performance. Consult Phoenix Contact's application notes for guidance on wire size selection.
• What is the maximum operating temperature range for this connector?
  The 1119810 connector is rated for operation in temperatures ranging from -40°C to +125°C. However, the temperature range may be limited by the specific application, PCB material, or wire insulation. Always verify the temperature rating for your specific use case.
