1140-151K-RC - Bourns

1140-151K-RC Details

• Manufacturer Part Number:

  1140-151K-RC

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  9 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  7

• Construction:

  Bobbin Core

• Core Material:

  FERRITE

• DC Resistance:

  0.04 Ω

• Inductance-Nom (L):

  150 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e2

• Lead Diameter:

  1.4478 mm

• Lead Length:

  12.7 mm

• Lead Spacing:

  29.21 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  38.1 mm

• Package Length:

  26.162 mm

• Package Style:

  Radial

• Rated Current-Max:

  8.3 A

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Copper (Sn/Cu)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  10%
