1140-331K - Bourns

1140-331K Details

• Manufacturer Part Number:

  1140-331K

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Bourns Inc

• YTEOL:

  0

• Construction:

  Epoxy Coated

• Core Material:

  FERRITE

• DC Resistance:

  0.074 Ω

• Inductance-Nom (L):

  330 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Lead Diameter:

  1.295 mm

• Lead Length:

  12.7 mm

• Lead Spacing:

  29.21 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  38.1 mm

• Package Length:

  26.162 mm

• Package Style:

  Radial

• Rated Current-Max:

  11.4 A

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.1 MHz

• Tolerance:

  10%
