115S-ACA0 - ATTEND

115S-ACA0 Details

• Manufacturer Part Number:

  115S-ACA0

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Attend Technology Inc

• Body Breadth:

  0.053 inch

• Body Depth:

  0.604 inch

• Body Length:

  0.528 inch

• Body/Shell Style:

  SOCKET

• Connector Type:

  PCB CONNECTOR

• Contact Gender:

  FEMALE

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  50 mΩ

• Contact Style:

  BELLOWED TYPE

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  2000 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  GLASS FILLED LIQUID CRYSTAL POLYMER

• Mating Contact Pitch:

  0.087 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  1

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• Plating Thickness:

  8u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  0.2 A

• Reference Standard:

  UL

• Terminal Pitch:

  1.1 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  6

• UL Flammability Code:

  94V-0
