The recommended torque is 6-8 in-lbs (0.7-0.9 Nm) to ensure secure mounting without damaging the connector or PCB.
Yes, the 1208 connector is designed to withstand vibration and shock, but it's recommended to use a locking screw or adhesive to secure the connector to the PCB to prevent loosening.
The 1208 connector has a plastic body and is not designed for outdoor or harsh environment applications. For such applications, consider using a connector with a more rugged design and environmental sealing.
No, the 1208 connector is designed for use with wire gauges 20 AWG to 24 AWG. Using a larger wire gauge may not fit properly or may damage the connector.
Yes, the 1208 connector is designed for automated assembly and can be used with pick-and-place machines and other automated assembly equipment.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
1208 Overview
Use the download button to access the 1208 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search
or try a keyword search, such as Power/Mains Transformers
