12246038X778 - Apem

12246038X778 Details

• Manufacturer Part Number:

  12246038X778

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  APEM Inc

• YTEOL:

  8

• Actuator Color:

  BLACK

• Actuator Finish:

  CHROME

• Actuator Length:

  0.681 inch

• Actuator Material:

  BRASS

• Actuator Type:

  STANDARD LEVER

• Additional Feature:

  PANEL MOUNTABLE

• Body Breadth:

  16 mm

• Body Height:

  15.1 mm

• Body Length or Diameter:

  16 mm

• Bushing Length:

  0.409 inch

• Bushing Type:

  15/32-32

• Contact (AC) Max Rating R Load:

  4A@125VAC

• Contact Current(AC)-Max:

  4 A

• Contact Current(DC)-Max:

  4 A

• Contact (DC) Max Rating R Load:

  4A@28VDC

• Contact Function:

  ON-ON

• Contact Resistance:

  0.01 mΩ

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  28 V

• Electrical Life:

  20000 Cycle(s)

• Housing Material:

  DIALLYL PHTHALATE

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BULK

• Sealing:

  EPOXY TERMINAL SEALED; IP67; SPLASH PROOF

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPDT

• Switch Type:

  TOGGLE SWITCH

• Terminal Length:

  0.161 inch

• Termination Type:

  SOLDER
