1274AS-H-2R2N=P3 - Murata Electronics

1274AS-H-2R2N=P3 Details

• Manufacturer Part Number:

  1274AS-H-2R2N=P3

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  CHIP

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Case/Size Code:

  3939

• Construction:

  Rectangular

• Core Material:

  FERRITE

• DC Resistance:

  0.0096 Ω

• Inductance-Nom (L):

  2.2 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  1

• Number of Terminals:

  2

• Package Height:

  5 mm

• Package Length:

  10 mm

• Package Style:

  SMT

• Package Width:

  10 mm

• Packing Method:

  TR, EMBOSSED, 13 INCH

• Rated Current-Max:

  8 A

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  YES

• Special Feature:

  DCR MEASURED AT 20%TOLERANCE

• Surface Mount:

  Reflow soldering

• Terminal Placement:

  DUAL ENDED

• Terminal Shape:

  WRAPAROUND

• Test Frequency:

  0.1 MHz

• Tolerance:

  30%
