1300530004 - Molex

1300530004 Details

• Manufacturer Part Number:

  1300530004

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mexico, Poland, USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Molex

• YTEOL:

  8

• Additional Feature:

  IP67

• Board Mounting Option:

  HOLE 0.087

• Body Breadth:

  1.5 inch

• Body Depth:

  0.68 inch

• Body Length:

  1.73 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  RJ CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  MODULAR RJ45

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulator Color:

  BLACK

• Insulator Material:

  ACRYLONITRILE BUTADIENE STYRENE

• Mixed Contacts:

  NO

• Mounting Option 1:

  11/4-7 UNC

• Mounting Option 2:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  2

• Number of Ports:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -20 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  2.54 mm

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1.5 A

• Shell Material:

  ACRYLONITRILE BUTADIENE STYRENE

• Terminal Length:

  0.13 inch

• Terminal Pitch:

  1.016 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  8
