1413009-9 - TE Connectivity

1413009-9 Details

• Manufacturer Part Number:

  1413009-9

• Brand Name:

  TE Connectivity

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.75

• Body Breadth:

  13.2 mm

• Body Height:

  10.1 mm

• Body Length or Diameter:

  23.8 mm

• Coil Current(DC)-Max:

  0.048 A

• Coil Operate Voltage(DC):

  6.9 V

• Coil Power:

  570 mW

• Coil Release Voltage(DC):

  1.5 V

• Coil Resistance:

  254 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  1.33A@12VAC

• Contact Current(AC)-Max:

  1.33 A

• Contact Current(DC)-Max:

  1.33 A

• Contact (DC) Max Rating R Load:

  1.33A@12VDC

• Contact Voltage(AC)-Max:

  12 V

• Contact Voltage(DC)-Max:

  12 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  300000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  3 ms

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  23.8mm x 13.2mm x 10.1mm

• Reference Standard:

  EN; IEC

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  1.5 ms

• Sealing:

  WATER PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER
