1415513C - Murata Electronics

1415513C Details

• Manufacturer Part Number:

  1415513C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  9 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Construction:

  Bobbin

• DC Resistance:

  0.68 Ω

• Inductance-Nom (L):

  1500 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Lead Diameter:

  0.54 mm

• Lead Length:

  10 mm

• Lead Spacing:

  23.1 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  14 mm

• Package Length:

  25.5 mm

• Package Style:

  Radial

• Package Width:

  24.4 mm

• Packing Method:

  BULK

• Rated Current-Max:

  1.3 A

• Self Resonance Frequency:

  1 MHz

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Pure Tin (Sn)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  10%
