146-02J08L - COILCRAFT

146-02J08L Details

• Manufacturer Part Number:

  146-02J08L

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  6

• Case/Size Code:

  2727

• Construction:

  Rectangular

• Core Material:

  CARBONYL

• DC Resistance:

  0.009 Ω

• Inductance-Max (L):

  0.088 µH

• Inductance-Min (L):

  0.068 µH

• Inductance-Nom (L):

  0.078 µH

• Inductor Application:

  RF INDUCTOR

• Inductor Type:

  VARIABLE INDUCTOR

• JESD-609 Code:

  e2

• Lead Diameter:

  0.51 mm

• Lead Length:

  3.5 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  11.43 mm

• Package Length:

  6.81 mm

• Package Style:

  Radial

• Package Width:

  6.81 mm

• Packing Method:

  TUBE

• Quality Factor-Min (at L-nom):

  100

• Rated Current-Max:

  10.5 A

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver (Sn/Ag)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  50 MHz
