1462052-6 - TE Connectivity

1462052-6 Details

• Manufacturer Part Number:

  1462052-6

• Brand Name:

  Axicom

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Factory Lead Time:

  55 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.25

• Additional Feature:

  RELEASE TIME TAKEN WITH DIODE IN PARALLEL

• Body Breadth:

  7.5 mm

• Body Height:

  10.5 mm

• Body Length or Diameter:

  15 mm

• Characteristic Impedance:

  50 Ω

• Coil Current(DC)-Max:

  0.012 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  140 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  1028 Ω

• Coil Voltage(AC)-Max:

  12 V

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  62.5VA@250VAC

• Contact (AC) Max Rating R Load:

  2A@250VAC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Power Rating R Load:

  60W@220VDC

• Contact (DC) Max Rating R Load:

  2A@220VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  220 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  1000 Vrms

• Dielectric Strength Between Open Contacts:

  600 Vrms

• End Contact Material:

  NICKEL

• End Contact Plating:

  GOLD

• Input Power-Max:

  50 W

• Input Switching Control Type:

  Random

• Insertion Loss-Max:

  -0.8 dB

• Insulation Resistance:

  1000000000000 Ω

• Isolation-Max:

  -30 dB

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  6

• Operate Time:

  8 ms

• Operating Frequency-Max:

  6000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Packing Method:

  BOX; TR

• Physical Dimension:

  14.9 X 7.5 X 10.5

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  RF RELAY

• Release Time:

  9 ms

• Sealing:

  IP67; RT3

• Surface Mount:

  NO

• Switching Time:

  17 ms

• Termination Type:

  SOLDER/QUICK CONNECT

• VSWR:

  1.4
