14SP-L1-02-W - Grayhill

14SP-L1-02-W Details

• Manufacturer Part Number:

  14SP-L1-02-W

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Grayhill Inc

• Actuator Material:

  THERMOPLASTIC

• Actuator Travel:

  1.524 mm

• Actuator Type:

  PUSHBUTTON

• Additional Feature:

  WHITE LED COLOR

• Body Length or Diameter:

  12.7 mm

• Center Contact Material:

  BERYLLIUM COPPER

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@30VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  1000000 Cycle(s)

• End Contact Material:

  BERYLLIUM COPPER

• End Contact Plating:

  GOLD

• Illumination:

  LED

• Insulation Resistance:

  10000000000 Ω

• Insulator Material:

  THERMOPLASTIC

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Surface Mount:

  NO

• Switch Function:

  SPST

• Switch Type:

  PUSHBUTTON SWITCH

• Terminal Material:

  BERYLLIUM COPPER

• Termination Type:

  SOLDER
