1534238-1 - TE Connectivity

1534238-1 Details

• Manufacturer Part Number:

  1534238-1

• Brand Name:

  TE Connectivity

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  10 Weeks, 1 Day

• Manufacturer:

  TE Connectivity

• Board Mounting Option:

  BOARD LOCK

• Body Breadth:

  1.482 inch

• Body Depth:

  1.738 inch

• Body Length:

  2.992 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  COMBINATION LINE CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Style:

  BLADE PIN-SKT

• DIN Conformance:

  NO

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• MIL Conformance:

  NO

• Mains Connector Rating:

  40A

• Mixed Contacts:

  NO

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Number of Rows Loaded:

  3

• Operating Temperature-Max:

  120 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  40 A

• Rated Voltage:

  28 V

• Reference Standard:

  UL

• Terminal Pitch:

  5 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  21

• UL Flammability Code:

  94-HB
