1558662-7 - TE Connectivity

1558662-7 Details

• Manufacturer Part Number:

  1558662-7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  64 Weeks, 3 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.75

• Body Breadth:

  21.5 mm

• Body Height:

  15.7 mm

• Body Length or Diameter:

  29 mm

• Coil Power:

  900 mW

• Coil Resistance:

  640 Ω

• Coil Voltage(DC)-Max:

  24 V

• Contact Current(AC)-Max:

  20 A

• Contact Current(DC)-Max:

  20 A

• Contact Voltage(AC)-Max:

  480 V

• Dielectric Strength Between Coil and Contacts:

  4000 Vrms

• Dielectric Strength Between Open Contacts:

  1500 Vrms

• End Contact Material:

  SILVER TIN ALLOY

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  29 X 21.5 X 15.7

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM B

• Relay Type:

  POWER/SIGNAL RELAY

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  18 g
