1558741-8 - TE Connectivity

1558741-8 Details

• Manufacturer Part Number:

  1558741-8

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  TE Connectivity

• YTEOL:

  5.98

• Body Breadth:

  16.5 mm

• Body Height:

  15.7 mm

• Body Length or Diameter:

  55 mm

• Coil Power:

  550 mW

• Coil Resistance:

  1047 Ω

• Coil Voltage(DC)-Max:

  24 V

• Contact Current(AC)-Max:

  8 A

• Contact Current(DC)-Max:

  8 A

• Contact Voltage(AC)-Max:

  400 V

• Dielectric Strength Between Coil and Contacts:

  4000 Vrms

• Dielectric Strength Between Open Contacts:

  1500 Vrms

• End Contact Material:

  SILVER TIN OXIDE

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Relay Action:

  MOMENTARY

• Relay Type:

  POWER/SIGNAL RELAY

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  29.5 g
