15DF15E1-A - TOKO

15DF15E1-A Details

• Manufacturer Part Number:

  15DF15E1-A

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DIP-5

• ECCN Code:

  EAR99

• Manufacturer:

  TOKO Inc

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  60%

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-PDIP-P5

• Line Regulation-Max:

  1%

• Load Regulation-Max:

  4.5%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  5

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -10 °C

• Output Voltage-Max:

  15.9 V

• Output Voltage-Min:

  14.1 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  16.8 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  10.16 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1.5 W

• Trim/Adjustable Output:

  NO

• Width:

  38.1 mm
