15KPA051C-SD-Q - Bourns

15KPA051C-SD-Q Details

• Manufacturer Part Number:

  15KPA051C-SD-Q

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  14 Weeks

• Date Of Intro:

  2019-10-17

• Manufacturer:

  Bourns Inc

• YTEOL:

  7.86

• Additional Feature:

  PD-CASE

• Breakdown Voltage-Max:

  62.7 V

• Breakdown Voltage-Min:

  52.04 V

• Breakdown Voltage-Nom:

  57.37 V

• Clamping Voltage-Max:

  76.3 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-218

• JESD-30 Code:

  R-PSSO-C1

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  15000 W

• Number of Elements:

  1

• Number of Terminals:

  1

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, 13 INCH

• Polarity:

  BIDIRECTIONAL

• Power Dissipation-Max:

  8 W

• Reference Standard:

  AEC-Q101

• Rep Pk Reverse Voltage-Max:

  51 V

• Reverse Current-Max:

  10 µA

• Reverse Test Voltage:

  51 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  C BEND

• Terminal Position:

  SINGLE
