15KPA120A-HRA - LITTELFUSE

15KPA120A-HRA Details

• Manufacturer Part Number:

  15KPA120A-HRA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  6.7

• Additional Feature:

  EXCELLENT CLAMPING CAPABILITY; HIGH RELIABILITY

• Breakdown Voltage-Max:

  146.8 V

• Breakdown Voltage-Min:

  134 V

• Breakdown Voltage-Nom:

  140.4 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  192.3 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Non-rep Peak Rev Power Dis-Max:

  15000 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Packing Method:

  TR, 13 INCH

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  8 W

• Reference Standard:

  IEC-61000-4-2, 4-4; MIL-STD-750; UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  120 V

• Reverse Current-Max:

  2 µA

• Reverse Test Voltage:

  120 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
