171224-1011 - Molex

171224-1011 Details

• Manufacturer Part Number:

  171224-1011

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Indonesia, Mainland China, Singapore

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Molex

• YTEOL:

  7.45

• Additional Feature:

  SHIELDED, ZSFP+, POLARIZED, OTHER STACKING CONNECTOR: 20 CONTACTS

• Board Mounting Option:

  PEG

• Body Breadth:

  1.016 inch

• Body Depth:

  2.49 inch

• Body Length:

  0.594 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  SFP CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  Matte Tin (Sn)

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  STAGGERED

• Contact Style:

  ZSFP+ TYPE

• DIN Conformance:

  NO

• Empty Shell:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Material:

  POLYETHYLENE

• JESD-609 Code:

  e3

• MIL Conformance:

  NO

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number Of PCB Rows:

  6+6

• Number of Ports:

  2

• Number of Rows Loaded:

  2+2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  0.7 mm

• Rated Current (Signal):

  0.5 A

• Terminal Pitch:

  0.8 mm

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  40
