The operating temperature range of the 17151692003 connector is -40°C to 125°C, as per the IEC 61984 standard.
Yes, the 17151692003 connector is designed to withstand high-vibration environments, with a vibration resistance of 10-2000 Hz, 10g acceleration, as per the IEC 61984 standard.
Yes, the 17151692003 connector is designed to be resistant to harsh environments, including high humidity and exposure to certain chemicals. However, it's essential to consult the datasheet and HARTING's application notes for specific guidance on environmental considerations.
The 17151692003 connector has a mating cycle life of at least 500 cycles, as per the IEC 61984 standard.
The 17151692003 connector is designed to be compatible with other HARTING connectors that share the same interface and mating configuration. However, it's essential to consult the datasheet and HARTING's application notes to ensure compatibility with specific connectors.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
17151692003 Overview
Use the download button to access the 17151692003 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like 17151,
or try a keyword search, such as Headers and Edge Type Connectors
