172-12 - Teledyne Technologies

172-12 Details

• Manufacturer Part Number:

  172-12

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Teledyne Technologies Inc

• YTEOL:

  7.7

• Additional Feature:

  LOW PROFILE

• Body Breadth:

  8.51 mm

• Body Height:

  7.11 mm

• Body Length or Diameter:

  8.51 mm

• Coil Current(DC)-Max:

  0.03 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  360 mW

• Coil Resistance:

  400 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@28VDC

• Contact Resistance:

  300 mΩ

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  500000 Cycle(s)

• End Contact Plating:

  GOLD

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  8

• Operate Time:

  6 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  8.51mm x 8.51mm x 7.11mm

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Release Time:

  3 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Switching Time:

  9 ms

• Terminal Finish:

  GOLD

• Terminal Length:

  0.018999237998476 inch

• Termination Type:

  WIRE WRAP
