1726118 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material. It's essential to follow the manufacturer's guidelines to avoid damaging the connector or PCB.
• Can I use this connector in high-vibration or high-shock applications?
  Yes, the 1726118 connector is designed to withstand vibrations and shocks. However, it's crucial to ensure proper mounting and screwing to prevent damage. Phoenix Contact recommends following the IEC 61373 standard for vibration testing and the IEC 61373-1 standard for shock testing.
• Is the connector suitable for use in harsh environments, such as high temperatures or humidities?
  The 1726118 connector is rated for operating temperatures between -40°C and 125°C and can withstand humidities up to 95%. However, it's essential to consider the specific environmental conditions of your application and ensure the connector meets those requirements.
• Can I use this connector with wire sizes other than the recommended AWG 20-24?
  While the datasheet recommends AWG 20-24 wire sizes, it's possible to use other wire sizes with the 1726118 connector. However, you should ensure the wire size is compatible with the connector's contact design and that the wire can withstand the maximum current rating of the connector.
• Are there any specific PCB layout considerations I should be aware of when using this connector?
  Yes, it's essential to follow Phoenix Contact's recommended PCB layout guidelines to ensure proper connector operation and prevent damage. This includes maintaining a minimum clearance of 1.5 mm between the connector and other components, as well as using a solder mask to prevent solder bridging.
