1782R-25J - API Delevan

1782R-25J Details

• Manufacturer Part Number:

  1782R-25J

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  AXIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  API Delevan

• YTEOL:

  6.75

• Construction:

  Tubular

• Core Material:

  IRON

• DC Resistance:

  0.3 Ω

• Inductance-Nom (L):

  1.6 µH

• Inductor Application:

  RF INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Lead Diameter:

  0.508 mm

• Lead Length:

  38.1 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  2.41 mm

• Package Length:

  6.35 mm

• Package Style:

  Axial

• Packing Method:

  TR, 14 INCH

• Quality Factor-Min (at L-nom):

  28

• Rated Current-Max:

  0.455 A

• Self Resonance Frequency:

  125 MHz

• Shape/Size Description:

  TUBULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Terminal Placement:

  AXIAL

• Terminal Shape:

  WIRE

• Tolerance:

  5%
